The Compact Substation, also known as a prefabricated substation or package substation, is a fully enclosed power distribution solution that integrates high-voltage switchgear, distribution transformers, and low-voltage switchgear into a compact and modular unit. Designed for urban power networks, industrial parks, commercial complexes, and renewable energy systems, it ensures safe, efficient, and space-saving power distribution.

Rated Voltage
6kv 10kv 15kv 20kv
Rated Current
630/1000/1250/1600/2000/2500/3150A
Model Number
YB-PRE
Certification
ISO CE
Standard
IEC60076
Warranty
2 Years
Application
Industrial
Rated Voltage
6kv 10kv 15kv 20kv
Rated current
630/1000/1250/1600/2000/2500/3150A
Protection Level
IP30/IP32/IP40/IP65/IP66
Appearance Treatment
Powder Coated Painting
Feature
Easy installation
   OEM
Accept



  • Marque :

    GE or Customized
  • FEO/ODM :

    Accept

Key Features

✅ All-in-One Design: Combines HV, transformer, and LV sections in a weatherproof, tamper-proof enclosure.



✅ Space-Saving: Up to 50% smaller footprint than traditional substations.



✅ Plug-and-Play: Factory-assembled and tested, ensuring fast on-site installation.



✅ Flexible Configuration: Compatible with ring main units (RMUs), air- or oil-filled transformers, and various LV panels.



✅ Safety & Protection: Equipped with interlocks, grounding, and protection relays.



✅ Smart Monitoring (Optional): SCADA/IoT-ready for real-time remote diagnostics.







---



Technical Specifications



Parameter Value



Rated Voltage (HV) 11kV / 22kV / 33kV

Rated Voltage (LV) 400V / 690V

Transformer Capacity 100kVA to 2500kVA

Frequency 50Hz / 60Hz

Cooling Type Oil-immersed / Dry-type

Protection Grade IP43 to IP55 (customizable)

Ambient Temperature -25°C to +45°C

Enclosure Material Galvanized steel / Aluminum alloy

Standards Compliance IEC 62271-202, IEC 60076, ISO 9001







---



Applications



📌 Urban Residential Areas



📌 Commercial Buildings & Malls



📌 Industrial Zones



📌 Construction Sites



📌 Renewable Energy Projects (e.g., solar/wind farms)







---



Why Choose Our Compact Substation?



🔧 High Reliability: Manufactured under strict quality control with certified components.



🌍 Environmental Adaptability: Corrosion-resistant, heatproof design for harsh conditions.



⏱ Reduced Installation Time: Minimal civil work required, operational within days.



💰 Cost-Efficient: Low operation & maintenance costs, long service life.







---



Customization Options



We offer flexible customization to meet your project needs:



HV configuration: Loop or radial



Transformer type: Oil or dry



SCADA integration



Smart metering



Remote monitoring







---



Certifications



✅ ISO 9001



✅ CE Certified


IEC60076



✅ Type-tested at accredited labs







---



Contact Us



Ready to power your next project with our compact substation solutions?

📩 Email: wong@anhuigreenenergy.com

📞 Phone: +86 0551-65879669

🌐 Website: https://www.ge-ele.com

---

!!!Note: Product specifications and configurations can be customized according to project requirements.
